Q-Full Flush Perimeter Light
LED helideck perimeter light designed to provide clear visual guidance for helicopter landing and take-off operations. Suitable for flush-mounted installation on TLOF areas of offshore and onshore helidecks. Engineered to meet ICAO Annex 14 requirements for helideck lighting systems.
Details
The Q-Full Flush Perimeter Light (TLOF) with IR option is 60 cd, 200 mW/sr perimeter light for all Helipad, Heliport and Airport facilities. The Q-Full Flush Perimeter Light (TLOF) is available in several configurations such as 100-240 VAC and 24 VDC and used in cold areas where snow shovels are being used to clean the area.
Downloads
Technical Specifications
Product Specifications
Application:
Classification:
Light Source:
Light Colour:
Light Intensity:
IR Light Intensity:
Colour Chromaticity:
Enclosure:
Mounting:
Input Voltage:
Inrush Current:
Maximum Amount of Units:
External Earthing:
Ambient Temperature:
Cable glands included:
Cable Outer Dimensions:
Consumption:
Life Expectancy:
Warranty:
IP Index:
Size & Dimensions
Weight:
Dimensions:
Packaging Dimensions:
Order Code
Q10FF03 – Q-Full Flush Perimeter Light (TLOF)
Input power 100-240 VAC: Q10FF03–11
Input power: 24 VDC: Q10FF03–12
Optional:
Including IR:
Input power 100-240 VAC: Q10FF03–11-IR
Input power: 24 VDC: Q10FF03–12-IR
Q-Reducer set M25-M20 with cable gland M20:
QM25-M20-03
